LW Pipeline Sewage Pump
DESCRIPTION
The LW series channel-type sewage pump is a new generation product developed byintegrating advanced foreign technology with domestic pump usage characteristics. It offersenergy-saving benefits, prevents clogging, and effectively handles solid particles and long-fiber waste. The pump’s unique impeller design, along with a new mechanical seal, efficiently handles materials with solid bodies and long fibers. Its improved efficiency and balanced impeller minimize vibrations during operation.
flow: 8~400m3/h
Liquid temperature: -0°C~+80°C
Head Range: 7~60m
voltage: 220V/380V
Voltage can be customized based
on your request
Material: Cast Iron/Cast Steel/Stainless Steel
| No. | Type | Caliber(mm) | Flow(m³/h) | Head(m) | Power(kW) | Rotational Speed(r/min) | Efficiency(%) | Head range of use(m) |
|---|---|---|---|---|---|---|---|---|
| 1 | 25LW7-18-0.75 | 25 | 7 | 18 | 0.75 | 2900 | 38.5 | 13-18 |
| 2 | 25LW8-22-1.1 | 25 | 8 | 22 | 1.1 | 2900 | 39 | 15-22 |
| 3 | 32LW12-15.1.1 | 32 | 12 | 15 | 1.1 | 2900 | 40 | 12-15 |
| 4 | 40LW10-10-0.75 | 40 | 10 | 10 | 0.75 | 2900 | 41.2 | 6-10 |
| 5 | 40LW10-15-1.1 | 40 | 10 | 15 | 1.1 | 2900 | 43 | 12-15 |
| 6 | 40LW15-15-1.5 | 40 | 15 | 15 | 1.5 | 2900 | 45.1 | 12-15 |
| 7 | 40LW15-25-2.2 | 40 | 15 | 25 | 2.2 | 2900 | 46 | 22-25 |
| 8 | 40LW15-30-2.2 | 40 | 15 | 30 | 2.2 | 2900 | 46 | 26-30 |
| 9 | 50LW20-7-0.75 | 50 | 20 | 7 | 0.75 | 2900 | 54 | 4-7 |
SCOPE OF
APPLICATION
District Heating
HVAC System
Condensation System
Water Treatment System
Water Supply System
Municipal Engineering
