HiPH3 Series
DESCRIPTION
Stainless steel materials
High pressure by multi-stage impeller
| Model | Max Flow(m3/h) | Max Head(m) | Rated Flow(m3/h) | Rated Head(m) | Inlet Size(mm) | Outlet Size(mm) | Max Pressure(bar) | Protection Class |
|---|---|---|---|---|---|---|---|---|
| HiPH3-300EH | 11.8 | 10.6 | 6 | 9 | 40 | 40 | 5.0 | IP44 |
| HiPH3-600EH | 15.5 | 16 | 9.6 | 12.4 | 50 | 50 | 5.0 | IP44 |
| HiPH3-1100EH | 22 | 19 | 11.5 | 17 | 50 | 50 | 5.0 | IP44 |
| HiPH3-1100QH | 22 | 19 | 11.5 | 17 | 50 | 50 | 5.0 | IP44 |
SCOPE OF
APPLICATION
District Heating
HVAC System
Condensation System
Water Treatment System
Water Supply System
Municipal Engineering
